Valve c/w Fittings:
The PanBlast UniFlo Control Valve is an air
operated inlet/outlet valve utilised to control the supply of compressed air to
the blast pot. Operation of the UniFlo Control Valve is via a pilot air signal
from the operator depressing the PanBlast AirFlo Control Handle.
PanBlast UniFlo Control Valve is a normally closed style valve, utilising a
spring to seal it during its un-activated closed state. Being a one-piece
design, the valve is easy to install onto existing equipment and is easily
accessable for maintenance, without requiring removal from the blast pot. Fitted
with 32mm (1-1/4") inlet/outlet ports and 19mm (3/4") exhaust port.
